The Hook-Up Flow Management Systems are pre-fabricated units combining the essential control components and connecting pipework associated with terminals units, into one compact, fully-assembled and tested unit ready for simple and fast on-site connection.

To complement the existing Hook-Up & Hook-Up Prime ranges Hattersley has introduced the Hook-Up Elite Prime : a compact and modular valve system that utilises the Elite Prime Pressure Independent Control Valve (Fig. 1934) for accurate flow, temperature and pressure control.

About Hookup

More about the Hook-Up Elite Prime Frequently Asked Questions PICV - UK Design & Manufacture

Installation & Operating Instructions

HD40 Series 80mm Series (EP range)

Hookup Products

Elite Prime Hook Up

Fig. HD40BSR1B

Hook-Up Elite Prime with PICV, FMD & Drain Port

Body Size: 40mm
Pressure rating: PN16
End Connnections: H-Body - BSP Taper
Terminal end - Compression/Solder

BIM File Available

Fig. HD40BSR2A

Hook-Up Elite Prime with PICV, BSRIA Flushing Drain & FMD

Body Size: 40mm
Pressure rating: PN16
End Connnections: H-Body - BSP Taper
Terminal end - Compression/Solder

BIM File Available

Fig. HD40BSS4B

Hook-Up Elite Prime with PICV, BSRIA Flushing Drain & 4-Port

Body Size: 40mm
Pressure rating: PN16
End Connnections: H-Body - BSP Taper
Terminal end - Compression/Solder

Fig. EP801P & Fig. EP801PF

Hook-Up Elite Prime with PICV & Strainer Drain

DN15/15 to DN20/20

Body Size: 80mm
Pressure rating: PN16
End Connnections: Flushing bypass body - BSP Parallel
Strainers & Tailpieces - BSP Taper

BIM File Available

Fig. EP701P & Fig. EP701PF

Hook-Up Elite Prime with PICV & Drain

DN15/15 to DN25/25

Body Size: 80mm
Pressure rating: PN16
End Connnections: Flushing bypass body - BSP Parallel
Strainers & Tailpieces - BSP Taper

BIM File Available

Fig. EP601PF

Hook-Up Elite Prime with PICV, Strainer Drain, FMD & Flushing Drains

DN15/15 to DN25/20

Body Size: 80mm
Pressure rating: PN16
End Connnections: Flushing By-pass body - BSP Taper
Strainers & Tailpieces - BSP Taper

BIM File Available

Fig. HD40BSR2BS

Hook-Up Elite Prime with PICV, BSRIA Flushing Drain, FMD & Strainer

Body Size: 40mm
Pressure rating: PN16
End Connnections: H-Body - BSP Taper
Terminal end - Compression/Solder

BIM File Available

Hook Up

Fig. C266 & H266

Manual Hook-Up (with Drain & Strainer)

DN15/15 - DN25/25

Body Size: 80mm
Pressure rating: PN16
End Connnections: System Side - BSP Female Taper
Terminal Side - BSP Female Taper

BIM File Available
